Do you know, that… ?

on the Reference geometry You can insert new plane in a certain way. If you need to add a plane tangent side surface of the cylinder, select the best plane passing through its center (usually rotating elements draw at the beginning of the, the plane so naturally there is) and a lateral wall. Inserted plane will default normal and to the desired tangent to the wall.

selection options Reverse offset results in the transfer plane to the opposite side.

You can also activate the angle and freely rotate the plane around.

If, however, you need to add a plane passing through the axis of the roller, you have to choose such a reference axis and reference plane. The natural choice would be temporary axis (automatically created – it must only show) and proces płaszczyzna passing through the center.

So why the plane of the insert?

This is usually necessary, If we need to create a plane offset angle.

An example of such trading presents the following picture. Of course you can rotate from zero to full angle, but it makes sense to the angle półpełnego – because of the stretched plane crosses the whole roller. You can insert multiple planes at the same time, However, with an identical angular displacement.

The case is somewhat complicated, 3D if the element is not embedded in the middle of the współrzędnych.Jeśli there are any plane parallel to the axis of the bore / cylinder – you can use. For example, after selecting the plane of symmetry and the borehole wall will create a plane perpendicular at the same time the tangent.

The hardest thing in my opinion, deal with the situation, in which there is no connection with the 3D system, ie de facto object is arbitrarily oriented in space.

I would recommend the use of such a situation 3D sketch, which is universal. You can draw two lines, one of which has a relationship concentrically the wall of the cylinder, and the other – perpendicular to the first – It is associated with a side wall or edge of the cylindrical (however, these do not always occur).

Insert plane after marking three points (three references) or by selecting a line and a point. It can also be inserted as normal to the curve at pointe – as below. Rotation of the plane of the axis of movement will be possible when the shorter line, because the plane is perpendicular to it.

There is one very simple method. insert Point (as a reference geometry) lying on the inside and check it against the wall and.

When you select a point and a cylindrical wall of the program inserts a plane tangent As a side wall Project.
